3M™ Dyneon™ Fluoroplastic PFA 6503PAZ
Generic Name: 全氟烷氧基 (PFA) - 提供方: 3M Advanced Materials Division
3M™ Dyneon™ Fluoroplastic Powder PFA 6503PAZ is a fluorothermoplastic powder designed for use in thin film powder coatings. Typical applications include non-stick surfaces, chemical vessel and tank liners, electrical insulation and low friction applications.
Features and Benefits
•Excellent electrostatics
•Excellent non-stick performance
•Outstanding flow and fluidization
•Good stress crack resistance
•Smooth surfaces
•Good transparency
•Non-wetting
•Heat resistant to 260℃ (500℉)
•Low friction
•Chemical resistance
•Process target: powder coating
材料特性:低摩擦系数、流动性高、耐化学品良好、食品接触的合规性、无润湿、无粘性、Good Clarity、Good ESCR (Stress Crack Resist.)
材料用途:衬里、电子绝缘、涂层应用
外观加工:清晰/透明、粉状、涂层
材料产地:北美洲、欧洲
物理性能 | 额定值 | 单位制 | 测试方法 |
密度/比重 | 2.15 | g/cm³ | ASTM D792 |
表观密度 | 0.80 | g/cm³ | DIN 53466 |
熔流率(熔体流动速率)(372℃/5.0 kg) | 3.0 | g/10 min | ASTM D1238 |
机械性能 | 额定值 | 单位制 | 测试方法 |
抗张强度(23℃) | 30.0 | MPa | ASTM D638 |
伸长率(断裂,23℃) | 380 | % | ASTM D638 |
弯曲模量 | 550 | MPa | ASTM D790 |
硬度 | 额定值 | 单位制 | 测试方法 |
肖氏硬度(邵氏D) | 60 | ASTM D2240 | |
热性能 | 额定值 | 单位制 | 测试方法 |
熔融温度 | 308 | ℃ | ASTM D4591 |
可燃性 | 额定值 | 单位制 | 测试方法 |
极限氧指数 | > 95 | % | ASTM D2863 |
